Hydraulic pumps
Air Hydraulic Pumps Series PP150-227-1000CAG
The hydraulic pumps of the series PP150- / PP227-1000CAG are complete units in a carrier, equipped with compressed air regulator, shut-off valve as well as a gauge for compressed air and hydraulic pressure. The pumps have a high oil feed rate and are delivered ready for operation. Depending on the type, the pressure range can be set to max. 1500 bar or to max. 2275 bar. Particularly popular are the pumps in combination with screw preloading devices, torque-screwed for preload or for industrial fittings.
Large, clear pressure gauges allow fast reading of air and hydraulic pressure in the system.
The built-in shut-off valve allows controlled hydraulic pressure.
Hoses and couplings, see accessories.
Technical Data
| Type | max. Work. pressure | Effective Oil volume | Capacity | Air pressure | Weight |
| MPa | cm³ | cm³/min. | bar | kgs | |
| PP150-1000CAG | 150 | 1000 | 320-27 | 6 - 10 | 11.8 |
| PP227-1000CAG | 227 | 1000 | 270-26 | 6 - 10 | 12.1 |
Technical Drawing
H = Compressed air pressure gauge
J = Hydraulic pressure gauge
G = Air regulator
I = Hydraulic - stop valve
Technical Data
| Type | max. Work. pressure | A | B | C | P1 + P2 Hydr. pressure | E |
| MPA | mm | mm | mm | connection | Air connection | |
| PP150-1000CAG | 150 | 329 | 232 | 500 | G¼" with 120° tight cone | G¼" |
| PP227-1000CAG | 227 | 329 | 232 | 500 | G¼" mit 120° tight cone | G¼" |
Application example
All information subject to change without further notice.
No responsibility is taken for the correctness of the named specifications.
